UPK-D4T Eclipse Talon M-LOK Direct
M-LOK Direct Mount Bayonet
This UPK-D4T Eclipse Talon M-LOK Direct has a Blade and Direct to M-LOK Mount Base made of Type III Hardcoat 7075-T6 Aluminum
- Blade has a triangular cross-section for improved off-axis loading
- Blood Groove- The functional slot enhances fluid drainage when piercing fluid cavities
- Retractable Bayonet Defensive Implement
- The Eclipse Offers Self-sheathing when retracted
- Retractable Blade automatically Locks at either position (open/closed)
-
SHARP, double-edged at TIP 1"length (A knife having dual effective cutting edges)
- Please see the D4 SS knives for FULL LENGTH doubled-edged options.
What’s included?
x1 UPK-D4T Eclipse M-LOK Direct
- Retractable Talon Blade and Base
- 3x Screws, M-LOK interface, and M-LOK nuts
Material Specifications:
- Blade TIP (Talon):
- Tungsten Carbide
- Hardness HRC: 78
- ~391 ksi Ultimate Compressive Strength
- 440C Stainless Steel
- Hardened to HRC: 60
- ~350+ ksi Tensile Strength
- Tungsten Carbide
- Blade Milled from 7075-T6 Aluminum
- Hardcoat Type III Anodized
- 80 ksi Tensile Strength
- M-LOK Direct Mount Base and interface Milled from 7075-T6 Aluminum
- Hardcoat Type III Anodized
- 80 ksi Tensile Strength
- M-LOK Screws
- Black Oxide Alloy Steel(140ksi) HRC 39
- M-LOK Nuts
- Block Oxide 440A Stainless Steel (220ksi) HRC 45
- Custom Button made in 7075-T6 Aluminum
- Black, Crimson, Patriot Blue, OD-Green, or Gold Hardcoat Type III Anodize
- Custom Screws made in 450 Stainless steel
- Heat Treated by Age Hardening to the H900 condition HRC 45
- 301 Stainless Steel Springs
- Cold work Hardened to a Spring Temper
Dimensions
- Extended length: 13.5 inches (343mm)
- Collapsed length: 9.2 inches (233mm)
- Closed Stickout from last M-Lok slot: Base Tip End to First M-LOK Screw(Center): 7.2 inches (183mm)
- Weight: 3.8 oz
Important Read:
7075-T6 Tempered Aluminum is a lightweight aluminum with steel like strength, one of the strongest Aluminum alloys available with a tensile strength of 80ksi. The Hardcoat Type III Anodize provides a resilient protective surface. for reference typical steel screws at a hardware store are typically rated 60ksi
It’s been a while since I saw something I had to have, but the price didn’t make it easy. Happy to report that the quality met my high expectations. Not to mention it shipped quickly, was easy to install and looks cool as hell. #HappyCustomer
The bayonet itself is great! Smooth operating, looks slick and intimidating. Customer service was spectacular! They called me mere hours after placing my order to make changes. Not to upsell me, but to make sure I had the most suitable setup. All around a great experience! Highly recommend you pick up a bayonet for your rifle or something for your pocket!
I recently purchased the upk- d40 eclipse talon m-LOK I seriously love it. Super cool super lightweight very efficient easy to mount. For as light as it is it's super sturdy. Everyone that has seen it loves it. Planning on buying another one as a gift for my son
This thing is great! Self sheathing, sharp as a scalpel, lightweight and perfect. 🤩🤩🤩🤩🤩
I received my bayonet quickly but I received it bent and missing mloc bolts,looks like maybe I got someone's return and unfortunately no one ever responded toy emails to replace it
